Merge pull request #7 from UPstartDeveloper/polish

Refactor README, add docker-compose.yml

Author: UPstartDeveloper

Dockerfile

@@ -1,7 +1,6 @@
 FROM python:3.6-slim
-COPY app/main.py /deploy/
-COPY app/config.yaml /deploy/
-WORKDIR /deploy/
+COPY app/ /app/
+WORKDIR /
 RUN apt update
 RUN apt install -y git
 RUN apt-get install -y libglib2.0-0

README.md

@@ -1,325 +1,46 @@
-# Fast_Image_Classification
+# *The* Fire Detection API
+![Project cover image](https://i.postimg.cc/1RNPLFF3/Screen-Shot-2021-09-02-at-9-58-41-AM.png)

-Code for https://towardsdatascience.com/a-step-by-step-tutorial-to-build-and-deploy-an-image-classification-api-95fa449f0f6a
+Deep learning has the power to potentially save millions of dollars (and more importantly, lives) in places like California where the annual "fire season" arrives every Fall.

-### Data
-Download data : <https://github.com/CVxTz/ToyImageClassificationDataset>
+We built this API to show how the technology can fight this and other crises, and inspire our students to do the same.

-### Docker
+## Getting Started

-```sudo docker build -t img_classif .```
+### Use the API
+To classify your own images, you can use the live API: use the link [here](https://fire-detection-api.herokuapp.com/docs) to read the documentation and send requests.

-```sudo docker run -p 8080:8080 img_classif```
+### Running Locally
+You can download this repository and run it using [Docker](https://www.docker.com/get-started):

-```time curl -X POST "http://127.0.0.1:8080/scorefile/" -H  "accept: application/json" -H  "Content-Type: multipart/form-data" -F "file=@337px-Majestic_Twilight.jpg"```
+```docker compose up```

-## Description
+Alternatively, you can also make a virtual environment and run it using the `uvicorn` package:

-Our objective in this small project is to build an image classification API from scratch.
-We are going to go through all the steps needed to achieve this objective :
+```
+$ python3 -m venv env  # creates a virtualenv
+$ source env/bin/activate  # now you're in the virtualenv
+$ uvicorn app.main:app --reload  # run the app

-* Data annotation (with Unsplash API + Labelme )
+```

-* Model Training ( With Tensorflow )
+## The Data and the Model
+The image dataset and model used for the production API will be documented on the [Releases](https://github.com/UPstartDeveloper/Fire-Detection-API/releases) page of this repository.

-* Making the API ( With Uvicorn and FastApi )
+## Making Your Own Deep Learning API

-* Deploying the API on a remote server ( With Docker and Google Cloud Platform )
+TBD

-## Data Annotation :
+## Deploying to Heroku

-One of the most important parts of any machine learning project is the quality and quantity of the annotated data. It is one of the key factors that will influence the quality of the predictions when the API is deployed.
+TBD
+## Stretch Challenges

-In this project we will try to classify an input image into four classes :
+In this project, we've worked with different tools like Tensorflow, Docker, FastAPI and Heroku. The next steps would be to two-fold:

-* City
+- For the **modelling** engineers: how would you improve the neural networks performance?
+- For the **MLOps** engineers: how would you improve the performance and scalability of the REST API in production?

-* Beach
-
-* Sunset
-
-* Trees/Forest
-
-I choose those classes because it is easy to find tons of images representing them online. We use those classes to define a multi-label classification problem :
-
-![Examples of inputs and targets / Images from [https://unsplash.com/](https://unsplash.com/)](https://cdn-images-1.medium.com/max/2000/1*buGA2Qk4KXqJMq5Xu5gffg.png)*Examples of inputs and targets / Images from [https://unsplash.com/](https://unsplash.com/)*
-
-Now that we have defined the problem we want to solve we need to get a sufficient amount of labeled samples for training and evaluation.
-To do that we will first use the [Unsplash](https://unsplash.com/) API to get URLs of images given multiple search queries.
-
-    # First install [https://github.com/yakupadakli/python-unsplash](https://github.com/yakupadakli/python-unsplash)
-    # Unsplash API [https://unsplash.com/documentation](https://unsplash.com/documentation)
-    import json
-    import os
-
-    from unsplash.api import Api
-    from unsplash.auth import Auth
-
-    with open('tokens.json', 'r') as f:
-        data = json.load(f)
-
-    client_id = data['client_id']
-    client_secret = data['client_secret']
-
-    redirect_uri = ""
-    code = ""
-
-    keyword = 'beach'
-
-    auth = Auth(client_id, client_secret, redirect_uri, code=code)
-    api = Api(auth)
-
-    photos = api.search.photos(keyword, per_page=1000, page=i)['results']
-
-    for photo in photos:
-        print(photo)
-        print(photo.id)
-        print(photo.urls)
-        print(photo.urls.small)
-
-We would try to get image URLs that are related to our target classes plus some other random images that will serve as negative examples.
-
-The next step is to go through all the images and assign a set of labels to each one of them, like what is shown in the figure above. For this it is always easier to use annotations tools that are designed for this task like [LabelMe,](https://github.com/wkentaro/labelme) it is a python library that you can run easily from the command line:
-
-    labelme . -flags labels.txt
-
-![Labelme user interface](https://cdn-images-1.medium.com/max/2000/1*4iIY7gR7ZYEc-qEW3HJmLg.png)*Labelme user interface*
-
-Using Labelme I labeled around a thousand images and made the urls+labels available here: [https://github.com/CVxTz/ToyImageClassificationDataset](https://github.com/CVxTz/ToyImageClassificationDataset)
-
-## Model
-
-Now that we have the labeled samples we can try building a classifier using Tensorflow. We will use MobileNet_V2 as the backbone of the classifier since it is fast and less likely to over-fit given the tiny amount of labeled samples we have, you can easily use it by importing it from keras_applications :
-
-    from tensorflow.keras.applications import MobileNetV2
-
-    base_model = MobileNetV2(include_top=False, input_shape=input_shape, weights=weights)
-
-Since it is a multi-label classification problem with four classes, we will have an output layer of four neurons with the Sigmoid activation ( given an example, we can have multiple neurons active or no neuron active as the target)
-
-### Transfer learning
-
-One commonly used trick to tackle the lack of labeled samples is to use transfer learning. It is when you transfer some of the weights learned from a source task ( like image classification with a different set of labels) to your target task as the starting point of your training. This allows for a better initialization compared to starting from random and allows for reusing some of the representations learned on the source task for our multi-label classification.
-
-Here we will transfer the weights that resulted from training in ImageNet. Doing this is very easy when using Tensorflow+Keras for MobileNet_V2, you just need to specify weights=”imagenet” when creating an instance of MobileNetV2
-
-    base_model = MobileNetV2(include_top=False, input_shape=input_shape, weights="imagenet")
-
-### Data augmentation
-
-Another trick to improve performance when having a small set of annotated samples is to do data augmentation. It is the process of applying random perturbations that preserve the label information ( a picture of a city after the perturbations still looks like a city ). Some common transformations are vertical mirroring, salt and pepper noise or blurring.
-
-![Data augmentation examples / Image from [https://unsplash.com/](https://unsplash.com/)](https://cdn-images-1.medium.com/max/3710/1*BNhj5p5uTfwF9yaeRDuBUQ.png)*Data augmentation examples / Image from [https://unsplash.com/](https://unsplash.com/)*
-
-To achieve this we use a python package called imgaug and define a sequence of transformation along with their amplitude :
-
-    sometimes = **lambda **aug: iaa.Sometimes(0.1, aug)
-    seq = iaa.Sequential(
-        [
-            sometimes(iaa.Affine(scale={**"x"**: (0.8, 1.2)})),
-            sometimes(iaa.Fliplr(p=0.5)),
-            sometimes(iaa.Affine(scale={**"y"**: (0.8, 1.2)})),
-            sometimes(iaa.Affine(translate_percent={**"x"**: (-0.2, 0.2)})),
-            sometimes(iaa.Affine(translate_percent={**"y"**: (-0.2, 0.2)})),
-            sometimes(iaa.Affine(rotate=(-20, 20))),
-            sometimes(iaa.Affine(shear=(-20, 20))),
-            sometimes(iaa.AdditiveGaussianNoise(scale=0.07 * 255)),
-            sometimes(iaa.GaussianBlur(sigma=(0, 3.0))),
-        ],
-        random_order=**True**,
-    )
-
-### Training
-
-We split the dataset into two folds, training and validation and use the binary_crossentropy as our target along with the binary_accuracy as the evaluation metric.
-
-We run the training from the command line after updating some configuration files :
-
-    # data_config.yaml for defnining the classes and input size**
-    input_shape**: [null, null, 3]
-    **resize_shape**: [224, 224]
-    **images_base_path**: **'../example/data/'
-    targets**: [**'beach'**, **'city'**, **'sunset'**, **'trees'**]
-    **image_name_col**: **'name'**
-
-    # training_config.yaml for defining some training parameters**
-    use_augmentation**: true
-    **batch_size**: 32
-    **epochs**: 1000
-    **initial_learning_rate**: 0.0001
-    **model_path**: **"image_classification.h5"**
-
-Then running the training script :
-
-    **export PYTHONPATH=$PYTHONPATH:~/PycharmProjects/FastImageClassification/**
-
-    **python train.py --csv_path "../example/data.csv" \
-           --data_config_path "../example/data_config.yaml" \
-           --training_config_path "../example/training_config.yaml"**
-
-![](https://cdn-images-1.medium.com/max/2048/1*azNZV0IqtYNajUzboMaYDw.gif)
-
-We end up with a validation binary accuracy of **94%**
-
-## Making the API
-
-We will be using FastAPI to expose a predictor through an easy to use API that can take as input an image file and outputs a JSON with the classification scores for each class.
-
-First, we need to write a Predictor class that can easily load a tensorflow.keras model and have a method to classify an image that is in the form of a file object.
-
-    **class **ImagePredictor:
-        **def **__init__(
-            self, model_path, resize_size, targets, pre_processing_function=preprocess_input
-        ):
-            self.model_path = model_path
-            self.pre_processing_function = pre_processing_function
-            self.model = load_model(self.model_path)
-            self.resize_size = resize_size
-            self.targets = targets
-
-        @classmethod
-        **def **init_from_config_path(cls, config_path):
-            **with **open(config_path, **"r"**) **as **f:
-                config = yaml.load(f, yaml.SafeLoader)
-            predictor = cls(
-                model_path=config[**"model_path"**],
-                resize_size=config[**"resize_shape"**],
-                targets=config[**"targets"**],
-            )
-            **return **predictor
-
-        @classmethod
-        **def **init_from_config_url(cls, config_path):
-            **with **open(config_path, **"r"**) **as **f:
-                config = yaml.load(f, yaml.SafeLoader)
-
-            download_model(
-                config[**"model_url"**], config[**"model_path"**], config[**"model_sha256"**]
-            )
-
-            **return **cls.init_from_config_path(config_path)
-
-        **def **predict_from_array(self, arr):
-            arr = resize_img(arr, h=self.resize_size[0], w=self.resize_size[1])
-            arr = self.pre_processing_function(arr)
-            pred = self.model.predict(arr[np.newaxis, ...]).ravel().tolist()
-            pred = [round(x, 3) **for **x **in **pred]
-            **return **{k: v **for **k, v **in **zip(self.targets, pred)}
-
-        **def **predict_from_file(self, file_object):
-            arr = read_from_file(file_object)
-            **return **self.predict_from_array(arr)
-
-We can use a configuration file to instantiate a predictor object that has all the parameters to do predictions and will download the model from the GitHub repository of the project :
-
-    **# config.yaml
-    resize_shape**: [224, 224]
-    **targets**: [**'beach'**, **'city'**, **'sunset'**, **'trees'**]
-    **model_path**: **"image_classification.h5"
-    model_url**: **"https://github.com/CVxTz/FastImageClassification/releases/download/v0.1/image_classification.h5"
-    model_sha256**: **"d5cd9082651faa826cab4562f60e3095502286b5ea64d5b25ba3682b66fbc305"**
-
-After doing all of this, the main file of our API becomes trivial when using FastAPI :
-
-    **from **fastapi **import **FastAPI, File, UploadFile
-
-    **from **fast_image_classification.predictor **import **ImagePredictor
-
-    app = FastAPI()
-
-    predictor_config_path = **"config.yaml"**
-
-    predictor = ImagePredictor.init_from_config_url(predictor_config_path)
-
-
-    @app.post(**"/scorefile/"**)
-    **def **create_upload_file(file: UploadFile = File(...)):
-        **return **predictor.predict_from_file(file.file)
-
-We can now run the app with a single command :
-
-    uvicorn main:app --reload
-
-This gives us access to Swagger UI where we can try out our API on a new file.
-
-![[http://127.0.0.1:8080/docs](http://127.0.0.1:8000/docs)](https://cdn-images-1.medium.com/max/2898/1*ka58fs87P-ptDS8aciP4Gw.png)*[http://127.0.0.1:8080/docs](http://127.0.0.1:8000/docs)*
-
-![Photo by [Antonio Resendiz](https://unsplash.com/@antonioresendiz_?utm_source=unsplash&utm_medium=referral&utm_content=creditCopyText) on [Unsplash](https://unsplash.com/s/photos/city?utm_source=unsplash&utm_medium=referral&utm_content=creditCopyText)](https://cdn-images-1.medium.com/max/5606/1*uPdQuS0Y4Esz5vYZk13Npw.jpeg)*Photo by [Antonio Resendiz](https://unsplash.com/@antonioresendiz_?utm_source=unsplash&utm_medium=referral&utm_content=creditCopyText) on [Unsplash](https://unsplash.com/s/photos/city?utm_source=unsplash&utm_medium=referral&utm_content=creditCopyText)*
-
-Uploading the image above gives up the following output :
-
-    {**
-      **"beach":** 0**,**
-      **"city":** 0**.**999**,**
-      **"sunset":** 0**.**005**,**
-      **"trees":** 0
-    **}
-
-Which is the expected output!
-
-We can also send a request via curl and time it :
-
-    time curl -X POST "[http://127.0.0.1:8080/scorefile/](http://127.0.0.1:8000/scorefile/)" -H  "accept: application/json" -H  "Content-Type: multipart/form-data" -F "file=[@antonio](http://twitter.com/antonio)-resendiz-VTLqQe4Ej8I-unsplash.jpg;type=image/jpeg"
-
-    >> {"beach":0.0,"city":0.999,"sunset":0.005,"trees":0.0}
-    >> real 0m0.209s
-    >> user 0m0.012s
-    >> sys 0m0.008s
-
-## Deploying the App
-
-### Docker
-
-Its easier to deploy an app if it is inside a container like Docker.
-
-We will create a Dockerfile with all the instructions needed to run our app after installing the correct environment :
-
-    **FROM** python:3.6-slim
-    **COPY** app/main.py /deploy/
-    **COPY** app/config.yaml /deploy/
-    **WORKDIR** /deploy/
-    **RUN** apt update
-    **RUN** apt install -y git
-    **RUN** apt-get install -y libglib2.0-0
-    **RUN** pip install git+https://github.com/CVxTz/FastImageClassification
-    **EXPOSE** 8080
-
-    **ENTRYPOINT** uvicorn main:app --host 0.0.0.0 --port 8080
-
-Install Docker :
-
-    sudo apt install docker.io
-
-Then we can run the Docker build :
-
-    sudo docker build -t img_classif .
-
-We finally run the container while mapping the port 8080 of container to that of the host :
-
-    sudo docker run -p 8080:8080 img_classif .
-
-### Deploying on a remote server
-
-I tried to do this on an ec2 instance from AWS but the ssh command line was clunky and the terminal would freeze at the last command, no idea why. So I decided to do the deployment using Google Cloud Platform’s App engine. Link to a more detailed tutorial on the subject [here](https://blog.machinebox.io/deploy-docker-containers-in-google-cloud-platform-4b921c77476b).
-
-* Create a google cloud platform account
-
-* install gcloud
-
-* create project project_id
-
-* clone [https://github.com/CVxTz/FastImageClassification](https://github.com/CVxTz/FastImageClassification) and call :
-
-    cd FastImageClassification
-
-    gcloud config set project_id
-
-    gcloud app deploy app.yaml -v v1
-
-The last command will take a while but … Voilaaa!
-
-![](https://cdn-images-1.medium.com/max/3702/1*UcHnFytWaAIpeM-ZL_3Dng.png)
-
-## Conclusion
-
-In this project, we built and deployed machine-learning powered image classification API from scratch using Tensorflow, Docker, FastAPI and Google Cloud Platform‘s App Engine. All those tools made the whole process straightforward and relatively easy. The next step would be to explore questions related to security and performance when handling a large number of queries.
+## Credits and Resources
+1. This *Towards Data Science* [blog](https://towardsdatascience.com/a-step-by-step-tutorial-to-build-and-deploy-an-image-classification-api-95fa449f0f6a) by Youness Mansar will give you a little more detail on how you can build a deployment-driven deep learning project (using the Google Cloud Platform's App Engine).
+2. Another [blog](https://towardsdatascience.com/how-to-deploy-your-fastapi-app-on-heroku-for-free-8d4271a4ab9#beb1) by  Shinichi Okada in *Towards Data Science* will give more details how to deploy FastAPI applications (such as this repo!) on Heroku specifically.

docker-compose.yml

@@ -0,0 +1,10 @@
+version: '3.7'
+
+services:
+  web:
+    build:
+      context: ./
+      dockerfile: Dockerfile
+    # command: uvicorn app.main:app
+    ports:
+      - "8080:8080"
