Lea

Structural reasoning engine for AI-native software engineering.

Lea transforms repositories into deterministic structural graphs — enabling AI agents and developers to reason about architecture, dependencies, execution flow, and system impact with minimal context and maximum precision.

Lynx discovers. Lea reasons.

Vision • Features • Architecture • .lea Metadata System • Installation • Quick Start • Command Guide • Export Targets • Architecture Guardrails • Ecosystem • Roadmap • Contributing

The Vision

Modern AI coding systems suffer from context window limitations, token inflation, and "context entropy." Most rely on probabilistic semantic chunking (embeddings), which often loses the architectural "big picture."

Software is symbolic, not just semantic. lea focuses on:

Structural Retrieval First — Symbols, dependencies, call graphs, and architectural boundaries.
Semantic Retrieval Second — Natural language understanding on top of structural certainty.

Lea is the structural counterpart to Lynx (the discovery engine). Together they form the PizenLabs ecosystem: Lynx discovers, Lea reasons, agents execute.

Key Features

Multi-Language AST Indexing: Native support for Go (go/ast) and Python, TypeScript, and Rust via Tree-sitter.
Structural Graph Engine: Models your codebase as a graph of functions, structs, interfaces, and their relationships (CALLS, IMPLEMENTS, USES, BELONGS_TO, FLOWS_THROUGH, IMPLEMENTS_METHOD, IMPORTS, DEPENDS_ON).
AI Context Compiler: Generates high-signal, markdown-optimized context for LLMs (Claude, GPT, Gemini) using deterministic retrieval with token-budget awareness.
Model Context Protocol (MCP): Expose your codebase structure directly to AI agents via a standardized protocol — exposes tools for symbol context, neighbor lookup, call tracing, execution path analysis, and architecture validation.
Blast Radius Analysis: Recursively trace incoming dependencies to determine the full impact of a code change, including direct/indirect callers, interfaces, and tests.
Symbol Discovery: Official symbol registry for discovering available functions, structs, interfaces, and packages — filterable by kind (--kind) and package (--pkg).
Architectural Guardrails: Define and enforce architectural boundaries using an explicit Allow/Deny rule engine with YAML-based layer configuration and pattern matching.
Interactive TUI: A rich, terminal-based (Bubble Tea) explorer for fuzzy symbol navigation and dependency browsing.
Control Flow & Architecture Tracing: Trace execution paths (flow) and recursive call graph hierarchies (trace) against architectural constraints.
Cross-Package Resolution: Full support for repository-wide symbol resolution, including internal module calls and external package dependencies with local variable type inference and struct field chain resolution.
Incremental & Reactive: Real-time graph updates using fsnotify without re-indexing the entire repository (watch).
.lea Metadata System: Generates deterministic machine-readable metadata (protocol.json, workspace.json, intent.json, memory.json, limitations.json) for AI agent integration.
Agent Export System: Generate bootstrap rule pointers for 11 AI agent ecosystems — Claude, Cursor, OpenCode, Codex, Gemini, Pi, Antigravity, Copilot, Aider, OpenHands, and Continue.
Interface Implementation Resolution: Deferred structural sub-typing resolution — matches concrete struct method sets against interface signatures and injects IMPLEMENTS and IMPLEMENTS_METHOD edges.

Architecture

lea is built with a modular, performance-oriented architecture designed for local execution:

Layer	Technology	Responsibility
Parser Layer	Native `go/ast` + Tree-sitter	Multi-language symbol extraction, call graph, control flow
Graph Engine	In-memory relationships	Symbol nodes, directed edge types (8 kinds), sequence ordering
Storage Layer	SQLite (via `modernc.org/sqlite`)	Persistent graph with recursive CTEs for complex traversals
Integration Layer	Bubble Tea (TUI) + MCP (stdio)	Human and AI agent interfaces
Workspace Layer	JSON metadata engine	Deterministic facts, protocols, limitations, memory

Architecture Diagram

       ┌────────────────────────────────────────────────────────┐
       │                 Local Filesystem Event                 │
       └───────────────────────────┬────────────────────────────┘
                                   │ (fsnotify)
                                   ▼
       ┌────────────────────────────────────────────────────────┐
       │ Incremental Parser Layer (Native Go AST / Tree-sitter) │
       └───────────────────────────┬────────────────────────────┘
                                   │ (Extracted Symbols)
                                   ▼
       ┌────────────────────────────────────────────────────────┐
       │   Storage Layer: SQLite Graph Engine (Recursive CTEs)  │
       └───────────────────────────┬────────────────────────────┘
                                   │
                    ┌──────────────┴──────────────┐
                    ▼                             ▼
       ┌────────────────────────┐    ┌──────────────────────────┐
       │   Integration Layer    │    │     Retrieval Engine     │
       │   (Bubble Tea TUI)     │    │   (MCP Server for AIs)   │
       └────────────────────────┘    └──────────────────────────┘

Graph Node Types

Type	Description
`function`	Standalone function
`method`	Method belonging to a type
`struct`	Structure or class definition
`interface`	Interface or protocol definition
`package`	Software package or namespace
`module`	Software module (file in non-Go languages)
`flow`	Data or control flow path

Graph Edge Types

Type	Description
`CALLS`	One symbol calls another
`IMPLEMENTS`	A type implements an interface
`USES`	One symbol uses/references another
`IMPORTS`	One file/package imports another
`BELONGS_TO`	Containment (method→type, type→package)
`DEPENDS_ON`	General dependency
`FLOWS_THROUGH`	Data/control flow between symbols
`IMPLEMENTS_METHOD`	Concrete method→interface method binding

.lea Metadata System

After running lea index, the .lea/ directory contains a complete deterministic metadata framework for AI agent integration:

File	Purpose	Schema
`graph.db`	SQLite structural graph database	Binary
`protocol.json`	Machine-to-Machine execution contract. Defines initialization lifecycle, execution pipeline (discover → reason), tool command registry, strict runtime rules, and hard boundary abort conditions.	JSON v1.0
`workspace.json`	Immutable repository facts. Contains repo root, module name, primary language, languages detected, frameworks, graph statistics (symbols, nodes, edges), lea version, and generation timestamp.	JSON v1.0
`intent.json`	Human-defined architectural boundaries. Product goals, architecture goals, ownership, constraints, and forbidden changes. Editable by developers to guide agent behavior.	JSON v1.0
`memory.json`	Dynamic operational storage. Tracks hotspots, frequently changed files, historical failures, and successful patterns. Evolves over time.	JSON v1.0
`limitations.json`	System blind spots. Logs unsupported languages, missing graph dimensions (data flow, type hierarchy, inheritance graph), and confidence limitations to prevent agent hallucination.	JSON v1.0

Agent Integration Workflow

The protocol.json enforces a strict lifecycle for AI agents:

Read .lea/protocol.json and .lea/workspace.json as first tool calls
Discover — Use lx search/lx resolve (or fallback bash equivalents) to find exact symbol coordinates
Reason — Use lea impact, lea context, lea flow for structural traversal
Modify — Only after completing discovery and reasoning phases

Installation

Go Install

go install github.com/PizenLabs/lea/cmd/lea@latest

Install Script (curl)

curl -fsSL https://raw.githubusercontent.com/PizenLabs/lea/main/scripts/install.sh | bash

Homebrew (Tap)

brew tap PizenLabs/tap
brew install lea

From Source

# Clone the repository
git clone https://github.com/PizenLabs/lea.git
cd lea

# Build the binary
make build

# Install to your GOPATH/bin
make install

Check Version

lea version

Current stable version: 0.2.0

Quick Start

1. Index your project

Initialize the structural graph for your repository and generate the .lea metadata framework:

lea index .

This creates .lea/graph.db, workspace.json, protocol.json, intent.json, memory.json, and limitations.json.

2. Explore symbols

List all symbols in the registry, filter by kind or package:

lea symbols
lea symbols auth -k interface    # Filter by kind
lea symbols -p internal          # Filter by package

3. Universal MCP Install (Recommended)

Register lea and lynx as MCP tools across all supported AI agents in one command:

lea mcp install

This auto-detects installed tools (Claude Code, VS Code Cline/Roo Code/Codex CLI, OpenCode, Pi, Zed, Gemini CLI, OpenClaw, Aider, Antigravity, Kiro, KiloCode) and injects the pizen-lea and pizen-lynx MCP entries into their config files — JSON, YAML, or TOML as appropriate.

Also generates ~/.config/pizen/instructions.md with the dual-tool orchestration protocol.

4. Start the MCP Server

Connect your favorite AI agent directly to your codebase:

lea mcp

Exposes MCP tools: get_symbol_context, find_neighbors, trace_calls, trace_execution_path, find_architecture_violations.

5. Export agent configurations

Generate bootstrap rule pointers for AI agent ecosystems:

lea export claude     # Creates CLAUDE.md
lea export cursor     # Creates .cursor/rules/lea.mdc
lea export gemini     # Creates GEMINI.md
lea export aider      # Creates AIDER.md
lea export copilot    # Creates .github/copilot-instructions.md
lea export pi         # Creates .pi/AGENTS.md

6. Interactive Exploration

Launch the TUI for fuzzy symbol search and dependency browsing:

lea tui

7. Analyze impact and context

# Blast radius analysis
lea impact AuthService

# AI-optimized context with token budget
lea context "func:internal/cli/commands:Execute" --budget 2000

# Trace call graph
lea trace "func:internal/cli/commands:Execute"

# Ordered execution flow
lea flow "func:internal/cli/commands:Execute"

# Immediate dependencies
lea neighbors AuthService

8. Watch for changes

Real-time incremental indexing without full re-index:

lea watch .

Command Guide

Command	Description	Example
`index`	Build or update the structural graph and metadata	`lea index .`
`symbols`	Discover and list symbols in the registry	`lea symbols auth -k interface`
`tui`	Open the interactive symbol explorer (Bubble Tea)	`lea tui`
`mcp`	Start the Model Context Protocol server (stdio)	`lea mcp`
`mcp install`	One-command MCP setup for lea & lynx across 11 AI tools	`lea mcp install`
`export`	Generate AI agent configuration bootstrap pointers	`lea export claude`
`context`	Generate budget-aware context for a symbol	`lea context AuthService --budget 2000`
`trace`	Follow the recursive call graph from a function	`lea trace "func:internal/cli:Execute"`
`flow`	Inspect ordered control flow within a symbol	`lea flow "func:internal/cli:Execute"`
`neighbors`	Find immediate dependencies of a symbol	`lea neighbors AuthService`
`impact`	Recursive blast-radius analysis (direct/indirect callers, tests, interfaces)	`lea impact TokenService`
`violations`	Check for architectural boundary violations	`lea violations --config arch.yaml`
`watch`	Watch for file changes and update the graph incrementally	`lea watch .`
`version`	Print the lea version	`lea version`

Makefile Targets

Target	Description
`build`	Build the binary to `bin/lea`
`test`	Run tests with -race and -cover
`lint`	Run golangci-lint
`install`	Build and install to GOPATH/bin
`index`	Build and run `lea index .`
`tui`	Build and launch the TUI
`mcp`	Build and start the MCP server
`watch`	Build and start the file watcher
`tidy`	Tidy go.mod and go.sum
`clean`	Remove build artifacts and `.lea/` data

Export Targets

Lea can generate bootstrap rule pointers for 11 AI agent ecosystems via lea export <target>:

Target	Output File	Ecosystem
`claude`	`CLAUDE.md`	Anthropic Claude Code
`cursor`	`.cursor/rules/lea.mdc`	Cursor IDE
`opencode`	`.opencode/AGENTS.md`	OpenCode Engine
`codex`	`.codex/AGENTS.md`	Codex Runtime
`gemini`	`GEMINI.md`	Google Gemini CLI
`pi`	`.pi/AGENTS.md`	Pi Coding Agent
`antigravity`	`.antigravity/AGENTS.md`	Antigravity Agent
`copilot`	`.github/copilot-instructions.md`	GitHub Copilot
`aider`	`AIDER.md`	Aider Chat
`openhands`	`.openhands/microagents/lea.yaml`	OpenHands Engine
`continue`	`.continue/rules/lea.md`	Continue Extension

Each export is a non-redundant deterministic pointer that instructs the AI agent to read .lea/protocol.json and .lea/workspace.json as its first action, enforcing the discover-before-reason lifecycle.

Architecture Guardrails

Lea supports defining architectural boundaries through YAML configuration. Create an arch.yaml file:

layers:
  - name: handler
    patterns: ["internal/handler/**"]
    allow: ["service", "domain"]
    deny: ["repository", "infrastructure"]

  - name: service
    patterns: ["internal/service/**"]
    allow: ["domain", "repository"]
    deny: ["handler", "infrastructure"]

  - name: repository
    patterns: ["internal/repository/**"]
    allow: ["domain"]
    deny: ["handler", "service"]

  - name: domain
    patterns: ["internal/domain/**"]
    allow: ["*"]
    deny: []

  - name: infrastructure
    patterns: ["internal/infrastructure/**"]
    allow: ["domain"]
    deny: []

settings:
  allow_unknown: true
  allow_self: true
  default_allow_all: true

Then validate:

lea violations --config arch.yaml

The architecture engine:

Maps files to layers via glob patterns
Evaluates CALLS, USES, DEPENDS_ON, and IMPORTS edges
Supports glob patterns with ** for recursive matches
Configurable behavior for unknown layers, self-references, and default allow/deny

Ecosystem Separation

Lea is part of the PizenLabs ecosystem alongside Lynx. The two tools have strictly separated responsibilities:

Aspect	Lynx	Lea
Mission	Convert intent into locations	Convert structure into reasoning
Primary Question	"Where should I look?"	"What happens if I change this?"
Input	Natural language	Exact symbol coordinates
Output	File paths, symbol references	Call hierarchy, execution paths, impact reports
Techniques	Semantic search, BM25, embeddings	Graph traversal, dependency analysis, architecture validation
Must Not	Build dependency graphs	Do semantic search/embeddings

Rule: Lynx discovers. Lea reasons. Never reverse this relationship.

Unified Workflow

Human Intent
     │
     ▼
   Lynx          ← Natural language search ("How is auth implemented?")
     │
     ▼
 Exact Symbol    ← "func:internal/auth:Login"
     │
     ▼
    Lea          ← Structural reasoning (impact, context, flow)
     │
     ▼
 AI Agent        ← Code modifications with architectural awareness

MCP Query Flow

sequenceDiagram
    autonumber
    actor Agent as AI Agent
    participant Lea as lea (MCP Server)
    participant DB as SQLite (Graph Engine)

    Agent->>Lea: find_symbol(name)
    Lea->>DB: Query exact Symbol URI/File
    DB-->>Lea: Return Node
    Lea-->>Agent: Return Symbol Coordinates

    Agent->>Lea: get_neighbors(URI)
    Lea->>DB: Traverse Edges (CALLS, USES, etc.)
    DB-->>Lea: Return Subgraph
    Lea-->>Agent: Return Markdown Context

Incremental Indexing Loop

[Filesystem Event: Modify/Create/Delete]
                   │
                   ▼
       ┌───────────────────────┐
       │   Debounce & Batch    │ (Gathers changes over ~500ms)
       └───────────┬───────────┘
                   │
                   ▼
       ┌───────────────────────┐
       │   Invalidation Stage  │ (Deletes affected Nodes & Edges in SQLite)
       └───────────┬───────────┘
                   │
                   ▼
       ┌───────────────────────┐
       │  Incremental Parsing  │ (Native go/ast or Tree-sitter AST extraction)
       └───────────┬───────────┘
                   │
                   ▼
       ┌───────────────────────┐
       │     Graph Commit      │ (Atomic SQL Transaction: Inserts new entities)
       └───────────────────────┘

Troubleshooting

Empty graph? Re-run lea index . and confirm your repository path is correct.
Missing symbols? Confirm the target language parser is supported (Go, Python, Rust, TypeScript). Non-Go languages use Tree-sitter — file a GitHub issue for unsupported languages.
Architecture checks fail? Ensure your rules file (e.g., arch.yaml) is present and valid YAML. Check layer patterns match your directory structure.
MCP not connecting? Verify the MCP server is running (lea mcp) and your AI agent is configured to connect to it via stdio.
MCP install skips a tool? That's expected — lea mcp install only injects entries into tools whose config directory already exists on your system, avoiding noise from uninstalled applications.
Missing agent on the install list? Run lea mcp install — it currently supports 11 targets (Claude Code, VS Code Cline/Roo/Codex CLI, OpenCode, Pi, Zed, Gemini CLI, OpenClaw, Aider, Antigravity, Kiro, KiloCode).
TUI shows no symbols? Ensure lea index . completed successfully — the TUI reads from .lea/graph.db.
Export file missing? Check that you ran lea export <target> from the repository root. The tool creates the necessary subdirectories automatically.

Roadmap

Usage Patterns

AI-Agent Workflow (MCP)

Find the target symbol to get exact file and symbol coordinates.
Expand context to pull immediate neighbors (CALLS, USES, IMPLEMENTS).
Trace execution to map the ordered call graph for the change.
Check boundaries against architecture rules before committing updates.

Developer Workflow (CLI/TUI)

Use lea tui for fuzzy symbol search and graph browsing.
Use lea context to generate prompt-ready context for web LLMs.
Use lea flow and lea trace to understand execution order and impact.
Use lea impact for pre-refactor safety analysis.

CI/CD Integration

Run lea violations --config arch.yaml in CI to prevent architectural drift.
Run lea index . after checkout to generate graph for downstream tools.

Project Structure

lea/
├── bin/lea                        # Compiled binary
├── cmd/lea/main.go                 # CLI entrypoint
├── internal/
│   ├── ai/context/compiler.go      # AI context compilation engine
│   ├── architecture/               # Architecture rule engine
│   │   ├── config.go              # YAML configuration types
│   │   ├── load.go                # Config loader
│   │   ├── matcher.go             # Layer-to-file pattern matching
│   │   └── violations.go          # Violation detection engine
│   ├── cli/commands/              # All CLI subcommands (cobra)
│   │   ├── context.go             # lea context
│   │   ├── export.go              # lea export (11 targets)
│   │   ├── flow.go                # lea flow
│   │   ├── impact.go              # lea impact (blast radius)
│   │   ├── index.go               # lea index (+metadata generation)
│   │   ├── mcp.go                 # lea mcp (server + install)
│   │   ├── neighbors.go           # lea neighbors
│   │   ├── root.go                # Root command + symbol resolution
│   │   ├── symbols.go             # lea symbols
│   │   ├── trace.go               # lea trace
│   │   ├── tui.go                 # lea tui
│   │   ├── violations.go          # lea violations
│   │   ├── version.go             # lea version
│   │   └── watch.go               # lea watch
│   ├── graph/contracts/           # Graph node/edge type definitions
│   │   ├── edge.go               # 8 edge types
│   │   └── node.go               # 7 node types
│   ├── mcp/
│   │   ├── install/install.go     # MCP install (11 target writers)
│   │   └── server.go              # MCP server (5 tools)
│   ├── parser/
│   │   ├── contracts/parser.go    # Parser interface
│   │   ├── golang/parser.go       # Go AST parser with deep resolution
│   │   ├── resolver.go            # Cross-package resolution
│   │   ├── calls.go               # Call extraction
│   │   └── treesitter/            # Python/Rust/TypeScript parsers
│   ├── storage/
│   │   ├── contracts/store.go     # Store interface
│   │   └── sqlite/sqlite.go       # SQLite implementation
│   ├── tui/app.go                 # Bubble Tea TUI
│   ├── watcher/watcher.go         # fsnotify file watcher
│   └── workspace/ignore/matcher.go # .gitignore-aware file matcher
├── configs/                       # Configuration templates
├── docs/                          # Additional documentation
│   ├── architecture/              # Ecosystem boundary docs
│   │   ├── ECOSYSTEM_BOUNDARIES.md
│   │   └── ORIENTATION.md
│   └── report-issues/             # Issue analysis archives
├── scripts/install.sh             # Shell install script
├── testdata/                      # Test fixtures
├── Makefile                       # Build automation
└── GUIDE.md                       # Extended usage guide

Contributing

Contributions are welcome! Please see CONTRIBUTING.md for guidelines on development, testing, and pull requests.

License

lea is licensed under the MIT License.

Built for the future of AI-native engineering. 🦾

Name		Name	Last commit message	Last commit date
Latest commit History 128 Commits
.github/workflows		.github/workflows
.opencode		.opencode
cmd/lea		cmd/lea
configs		configs
docs		docs
internal		internal
scripts		scripts
testdata		testdata
.editorconfig		.editorconfig
.gitignore		.gitignore
.golangci.yml		.golangci.yml
.goreleaser.yml		.goreleaser.yml
CHANGELOG.md		CHANGELOG.md
CODE_OF_CONDUCT.md		CODE_OF_CONDUCT.md
CONTRIBUTING.md		CONTRIBUTING.md
GUIDE.md		GUIDE.md
LICENSE		LICENSE
Makefile		Makefile
README.md		README.md
SECURITY.md		SECURITY.md
go.mod		go.mod
go.sum		go.sum

Uh oh!

Folders and files

Latest commit

History

Repository files navigation

Lea

Structural reasoning engine for AI-native software engineering.

The Vision

Key Features

Architecture

Architecture Diagram

Graph Node Types

Graph Edge Types

.lea Metadata System

Agent Integration Workflow

Installation

Go Install

Install Script (curl)

Homebrew (Tap)

From Source

Check Version

Quick Start

1. Index your project

2. Explore symbols

3. Universal MCP Install (Recommended)

4. Start the MCP Server

5. Export agent configurations

6. Interactive Exploration

7. Analyze impact and context

8. Watch for changes

Command Guide

Makefile Targets

Export Targets

Architecture Guardrails

Ecosystem Separation

Unified Workflow

MCP Query Flow

Incremental Indexing Loop

Troubleshooting

Roadmap

Usage Patterns

AI-Agent Workflow (MCP)

Developer Workflow (CLI/TUI)

CI/CD Integration

Project Structure

Contributing

License

About

Resources

License

Code of conduct

Contributing

Security policy

Uh oh!

Stars

Watchers

Forks

Releases 2

Packages 0

Uh oh!

Contributors

Uh oh!

Languages

Packages
