The CSS compiler previously rejected anything beyond two-stop linear gradients at 0/90/180/270 degrees and two-stop radial gradients at the center, falling back to CEF-rasterized images for everything else. filter/backdrop-filter properties were ignored entirely. This change moves the full CSS gradient range and filter:blur into native primitives end-to-end: * New GradientDescriptor (kind, cycle method, multi-stop colors, shape, extent, center, radii, conic from-angle) attached to Style alongside new BACKGROUND_GRADIENT_LINEAR / _RADIAL_FULL / _CONIC / _REPEATING_LINEAR / _REPEATING_RADIAL types, plus filterBlurRadius / backdropFilterBlurRadius fields with accessors. * Graphics + CodenameOneImplementation grow fillLinearGradientWithStops, fillRadialGradientWithStops, fillConicGradient and a blurRegion hook. Software rasterizer in the base impl guarantees correctness on every port. * Resource format bumped to v1.13: new bgGradientEx, filterBlur and backdropFilterBlur theme entries; Resources.java reader and EditableResources writer round-trip the new data (binary + XML). * CSS compiler parses arbitrary angles, multi-stop with optional positions, conic-gradient, repeating-*, full radial syntax (circle/ellipse + four extents), plus filter: blur() and backdrop-filter: blur(); native filter rendering removed from the requiresBackgroundImageGeneration condition. * JavaSE uses Java2D LinearGradientPaint / RadialGradientPaint with cycle methods and AffineTransform for ellipses. Android wires multi-stop LinearGradient / RadialGradient / SweepGradient shaders, with the AndroidAsyncView legacy paint path capturing a defensive descriptor copy. iOS falls back to the software rasterizer (correct output, transforms and clip preserved); CIGaussianBlur already provides image-level filter:blur. * Developer guide (css.asciidoc, graphics.asciidoc, Native-Themes.asciidoc) and the initializr Claude Code skill css reference updated with the new syntax and the filter:blur / backdrop-filter:blur properties. Verified by mvn compile across core, css-compiler, JavaSE, iOS Java side, and Android (with JDK 17) — all clean. Co-Authored-By: Claude Opus 4.7 (1M context) <noreply@anthropic.com>
…APIs CI fixes: * CodenameOneImplementation: java.lang.Math.atan2 isn't in the CN1 core stub (ParparVM ships a Java 5-era subset); the iOS build broke on fillConicGradient's software rasterizer. Switch to MathUtil.atan2. * CSSBorder.RadialGradient.toCSSString() no longer throws, so update CSSBorderTest.testRadialGradient to assert the new behavior (returns a valid radial-gradient(...) string instead of an exception). * CSSTheme.CN1Gradient.parse(): wrap the legacy linear/radial parsers in try/catch so inputs the extended parser can handle (e.g. "to bottom right" - the legacy parser tries to read the second side keyword as a color and throws) fall through to the extended parser cleanly. New screenshot tests (added to Cn1ssDeviceRunner): * graphics/DrawGradientStops - exercises the new low-level Graphics primitives directly (fillLinearGradientWithStops at 45deg/REFLECT, repeating-linear stripes, multi-stop radial circle + ellipse, conic rainbow). Inherits AbstractGraphicsScreenshotTest so each tile is rendered four ways (AA on/off, direct/buffered) - per-port differences in stop interpolation, angle math, and shader matrices surface as pixel diffs. * graphics/GaussianBlur - validates the platform's gaussianBlur(Image, float) primitive used to back filter:blur. Four tiles: unblurred reference, light blur (1.5mm), heavy blur (4mm), and a heavy blur over a gradient-filled source to expose blur-kernel artifacts against high-frequency content. Density-aware radii (CN.convertToPixels) keep the visual blur similar across DPIs. * CssGradientsScreenshotTest - end-to-end CSS gradient test: theme.css declares eight UIIDs covering angled multi-stop linear, "to side1 side2", mismatched-alpha linear, radial farthest-corner, elliptical radial, conic, repeating-linear, repeating-radial. The test asserts each tile carries the expected BACKGROUND_GRADIENT_* type and a non-null GradientDescriptor BEFORE taking the screenshot, so a silent CSS compiler regression (e.g. dropping support for one form) fails explicitly rather than producing a "looks slightly different" image. * CssFilterBlurScreenshotTest - end-to-end filter: blur() and backdrop-filter: blur() test. Four tiles cover no-blur, blur(2px), blur(8px), and backdrop-blur(12px); the test asserts each Style's filterBlurRadius / backdropFilterBlurRadius before screenshotting. Co-Authored-By: Claude Opus 4.7 (1M context) <noreply@anthropic.com>
PR #4929 (May 12) bumped codenameone-javase's surefire to 3.2.5 so its JUnit Jupiter tests would run. Surefire 3.x renamed `failIfNoTests` -> `failIfNoSpecifiedTests`, and designer.yml's reactor build invokes `-Dtest=SimpleXmlParserTest -DfailIfNoTests=false` to suppress "no tests matched" on intermediate modules. The flag was silently ignored by 3.2.5, so the codenameone-javase test phase began failing on the next run. designer.yml's path filter excludes `maven/javase/**`, so the bug didn't surface on master after the surefire bump - it only manifested on a PR that touches the designer workflow's trigger paths (maven/css-compiler/**, maven/designer/**, or CodenameOneDesigner/**). This PR touches css-compiler, so it surfaces here. Pass both flag names so each surefire version finds the one it understands. codenameone-javase (3.2.5) reads `surefire.failIfNoSpecifiedTests`; peer modules still on parent-pom 2.21.0 read `failIfNoTests`. Co-Authored-By: Claude Opus 4.7 (1M context) <noreply@anthropic.com>
The Android port's Ant javac uses US-ASCII source encoding and rejects em dashes and degree signs the build-test (8/17) jobs surfaced. Replace em dashes with hyphens and degree signs with "deg" in the comments added by this branch: - CodenameOneImplementation: 3 comments (Conic sweep, CSS conic-gradient axis, blurRegion fallback). - Graphics.fillLinearGradientWithStops / fillConicGradient javadoc. - JavaSEPort blurRegion fallback comment. - theme.css filter:blur section header. - CssGradientsScreenshotTest class javadoc + UIIDs comment. Pre-existing non-ASCII in Cn1ssDeviceRunner (4 lines from PR #4884) is left alone - it lives in hellocodenameone test code which uses UTF-8 javac, not the Android-port Ant build. Co-Authored-By: Claude Opus 4.7 (1M context) <noreply@anthropic.com>
build-test (8) runs SpotBugs and fails on three new findings: * IM_BAD_CHECK_FOR_ODD in sampleStops's REFLECT cycle: `intp % 2 == 1` silently does the wrong thing for negative ints (the JLS specifies `-1 % 2 == -1`). In this code path `intp` is the absolute-valued floor and is always non-negative, but SpotBugs can't see that. Switch to `(intp & 1) != 0` which is unambiguous and slightly faster. * FE_FLOATING_POINT_EQUALITY in Style.setFilterBlurRadius and setBackdropFilterBlurRadius: `this.field != radius` directly compares floats, which mishandles NaN and -0/+0. Use `Float.compare` so the field/method semantics match the rest of Style (the existing iconGap setter already uses an epsilon-based check via `Math.abs(...) > 1e-4`, but Float.compare is more standard for "should we update"). Co-Authored-By: Claude Opus 4.7 (1M context) <noreply@anthropic.com>
build-test (8) PMD pass surfaced two cosmetic findings: - UnnecessaryConstructor: drop the explicit zero-arg constructor; the compiler provides one for free with the same visibility. - OneDeclarationPerLine: split `float rx, ry;` into two declarations inside computeRadii. Co-Authored-By: Claude Opus 4.7 (1M context) <noreply@anthropic.com>
Three reviewer-driven changes:
