munchkeen

munchkeen is a Solid-first interactive graph exploration toolkit.

In v1, Cytoscape.js is the first renderer adapter and the first production renderer, but the library is architected around a renderer-neutral graph, projection, layout, scene, and renderer-command pipeline.

Direction

munchkeen is not intended to be only a thin Cytoscape wrapper.

The package has three public entrypoints:

• munchkeen: the default Solid Graph integration surface
• munchkeen/core: the pure graph pipeline and state-transition surface
• munchkeen/cytoscape: the typed Cytoscape integration and escape hatch surface

The default root entrypoint stays friendly and intentionally leaves low-level renderer session typing opaque. If you want to work directly with the pure pipeline, use munchkeen/core. If you want typed Cytoscape sessions, command timing, or adapter-level helpers, use munchkeen/cytoscape.

Install

Install it:

npm i munchkeen
# or
yarn add munchkeen
# or
pnpm add munchkeen

Entry Points

munchkeen

Use the default entrypoint when you want a controlled Solid graph component with the built-in Cytoscape renderer.

import { Graph, edgeId, nodeId } from "munchkeen";

const ada = nodeId("ada");
const charles = nodeId("charles");
const collaborates = edgeId("collaborates");

<Graph
  graph={{
    nodes: [
      { id: ada, label: "Ada Lovelace" },
      { id: charles, label: "Charles Babbage" },
    ],
    edges: [{ id: collaborates, source: ada, target: charles, label: "collaborates" }],
  }}
  layout={{ kind: "breadthfirst", root: ada }}
  view={{
    focus: ada,
    neighborhood: { radius: 1, direction: "both" },
  }}
/>;

Reference example: examples/minimal-graph.tsx

munchkeen/core

Use the core entrypoint when you want to drive validation, projection, layout, scene construction, and diffing yourself.

import {
  buildRenderScene,
  diffScene,
  isLeft,
  projectGraph,
  runLayout,
  validateGraph,
} from "munchkeen/core";

const validated = validateGraph(graph);

if (isLeft(validated)) {
  throw new Error(validated.left.map((error) => error.message).join(", "));
}

const projected = projectGraph({ graph: validated.right });
const laidOut = runLayout({ graph: projected.right });
const scene = buildRenderScene({ graph: laidOut.right });
const commands = diffScene(undefined, scene);

Reference example: examples/core-pipeline.ts

munchkeen/cytoscape

Use the Cytoscape entrypoint when you want the typed adapter surface directly.

import { createCytoscapeRenderer } from "munchkeen/cytoscape";

const renderer = createCytoscapeRenderer();
const created = renderer.createSession();

if (created._tag === "Right") {
  created.right.syncViewport();
}

This is the companion surface for low-level renderer authoring. The root GraphRenderer type intentionally stays more opaque.

Examples

• Minimal root-component example: examples/minimal-graph.tsx
• Core pipeline example: examples/core-pipeline.ts
• Focused neighborhood example: examples/focused-neighborhood.tsx

Tests

Run the client and SSR test suites:

pnpm test

Generate a local coverage report:

pnpm test:coverage

Vitest writes coverage artifacts to coverage/.

Documentation Playground

The repository includes a docs playground built from the runnable examples in examples/.

pnpm docs:dev

That starts the Vite app in dev/, which now acts as the local documentation surface for the package.

To produce the static docs bundle:

pnpm docs:build

The output is written to dev/dist.

dev/dist can be published to any static hosting provider.

Pure Core vs Adapter Escape Hatches

Pure core concepts live in munchkeen/core:

• graph data and branded ids
• view transitions
• validation
• projection
• pure layouts
• semantic scene construction
• scene diffing into render commands

Renderer-specific concerns live outside the pure core:

• DOM attachment
• viewport synchronization
• Cytoscape stylesheet generation
• Cytoscape event wiring
• command execution timing
• Cytoscape-native layouts

That split is deliberate. The pure pipeline owns semantic graph state. Renderers interpret semantic commands at the boundary.

Current Limitations

• Cytoscape is the only production renderer today.
• The root Graph component is browser-oriented because it owns a DOM viewport.
• The pure core is first-class through munchkeen/core, but advanced staged types are still a more expert-facing surface than the root component API.
• Renderer timing currently reports adapter-local batch duration and frame-budget usage, but it does not yet provide a full live benchmark dashboard for minimal diff versus full replace outside the development harness.
