Course links

Instruction

Ideas

  • What if we dropped spelling corrector and just used Phase one, or part of phase one as the gateway test?
  • What if we had a Pet Shop that was the example project used through the whole class. That would parallel the chess project, but not actually implement Chess for them.
  • Several students had a hard time trying to understand how to get started with phase 3. What if instead of JavaDocs we had them write a sequence diagram for each of the endpoints. Then they would create an HTTP server that stubs out each of the endpoints.
  • Fix test server facade to handle not having a body in some of the responses. Those HTTP endpoints should be returning no content 204. Or we should change the spec to return an empty object.
  • Type adapter is problematic and confusion. We could drop the use of interfaces for anything but the database access, or we need to figure out how to teach it better.
  • If we have an endpoint for getting valid moves we can drop the shared code because the client will no longer need to know how pieces move. This will make it easy to write an Web version of the client. This will also reduce complexity on the project configuration front.
  • A lot of students are using ChatGPT and totally getting confused by just pasting it into their code.
  • Use the deliverable overview graph at the beginning of the class to help describe the 10k view.
  • Use BCrypt to hash passwords.
  • I didn't use the slides much. I either just worked from code examples, went right off the github content, or wrote my own slides (concurrency, SQL, Relational Databases, Design principles. The slides seems had too many words on them or used examples that I thought were too complex.

Schedule

Nov 12 Security Nov 19 Thanksgiving no class Nov 26 #5 due (27) WebSocket, phase 6, concurrency Dec 3 No class Dec 10 - 14 Demo day? Live chess? Review? #6 due (14) Dec 17 finals

Future work for chess

  • remove database.java
  • remove interfaces
  • use interfaces for data access
  • Make tests start server automatically

Work to do now

  • write final %5
  • bonus for survey 5%

Record of experience

Week Day Topics Notes
1 1 Course Intro, Java Fundamentals This felt a bit rushed. I would rather have some assignment in the first week to build some deliverable. Perhaps if we dropped Spelling Corrector we could have a phase -1 that introduced the Chess project, talked about Git, set up your Git repo, and created the intelliJ project. The deliverable would be their GitHub URL with a few commits.
2 Java Fundamentals, Spelling Corrector This felt a bit rushed. But with their background of C++ I think they all got it pretty well. Here you could teach phase 0 which is just the chess moves. Phase 1 would then be game tests and include en passant and castling.
2 3 Objects & Classes, Java Inheritance, Spelling Corrector This was fine. inheritance goes well when discussing the Java Object class as the base for all objects with its inherited methods.
4 Copying Objects, Object oriented design I threw in a discussion about OOP principles and domain driven design in here. I felt that provided a foundation for why we program with objects.
3 5 Java Exceptions, Java Collections This was a bit light, but it enabled me to catch up from the impact of the holiday.
6 Design Principles, Chess #1 I like focusing on design principles. It feels like an important topic for a software construction class. I don't know how you talk about construction without it. I think we need at least one class spent on this.
4 7 Git, Nested/Inner Classes I spent 30 minutes talking about Git. This needs to be earlier. Like day one. I used the context of setting up the chess project to provide the foundation for this. 15 minutes talking about nested classes.
8 JSON & Serialization, Generics, Lambdas Timing works fine. Lambdas are a great follow on for inner classes. I found myself teaching about generics all through the previous lectures since they are such a basic part of collections. Maybe move them up to the discussion on collections.
5 9 HTTP Curl Timing works fine. I was surprised that HTTP filled the whole time. Using Curl throughout the discussion worked well.
10 Web API Implementation (SparkJava) This seems like it should go after introducing phase #3. I covered both the client and server using SparkJava within the allotted time. But had a bit of trouble fitting error and exception handling on the server. This is named really strangely. Isn't it really implementing client and server HTTP?
6 11 Chess #2, Chess #3 I would have liked more time on this. I went in deep on different options for the objects that get passed between http/service/db. I also went deep on where is the proper level to test at. We should have instruction for JavaDocs that describes the basics.
12 Writing Quality Code Style Checker (e.g., CheckStyle) This fit well. I actually did quality before I introduced phase 2 and phase 3. That was probably a mistake since they only have 5 days to complete phase 2. The main thing to teach here is that quality style changes with time, and we need to focus on 1-did I meet the customer need, 2-is the code maintainable and extensible.
7 13 Unit Testing Code Coverage / Coverage tools Plenty of time to cover this. I talked about TDD from the instruction and then switched to the chess tests as examples. I then went to my code and wrote some tests and show how the coverage worked. Also demonstrated parameterization with the Database Memory and SQL implementation.
14 Relational Databases, MySQL This was a bit light, but I filled it with discussions about designing schemas.
8 15 SQL, JDBC (moved JDBC to next lecture) (Pet Shop introduced) I took the whole day talking about SQL and that seemed about right. I did cover joins and so that took a bit extra. I am planning on doing JDBC and phase 3 in the next lecture.
16 MySQL Project Design (Database) (JDBC taught here) I spend most of the time talking about JDBC and about 10 minutes talking about the project. The adapter is a significant complexity that the project introduces. It might be better to move the discussion on Serialization later in the class. Or at least have some sort of review about Gson adapters.
9 17 Logging, Debugging <FLEX> Debugging should be early in the course. Doing both debugging and logging just barely fit in to one class. I never got to defensive programming, but I think we could just drop this.
18 Defensive Programming <FLEX> I cancelled class for this and just used it as a study period. I think we can skip this topic.
10 19 Project Design (Pre Game) Console UI (moved pregame) to next lecture I spent quiet a bit of time reviewing the deliverable diagram and introducing Pet Store. Console was easy to explain. I finished 15 minutes early.
20 Web Sockets (Spark for Java) (moved to after security) This was moved to be on the same day as Project Design (Game Play) and worked fine.
11 21 Security (hashing) I didn't think there is enough material here, but when I sprinkled in the importance of security, examples from the real world, and discussed it in the context of the chess program it was perfect.
22 Security (encryption) Same as above.
12 23 Project Design (Game Play) and Client HTTP Access Worked fine. I thought it was going to be tricky to explain, but either the students don't get it or I did a good job.
24 Concurrency in server, Simple Java Threading, Race conditions in chess client and server This was fun. Had the students act out the pizza ordering.
13 25 Automated Builds (Maven)
26 Final Exam Review
14 27 I ended up cancelling 5 classes almost two full weeks of class. This seems a bit weird to me. I would much rather work in some enrichment topics.
28

IntelliJ Cheat Sheet

  • Turn on format on save in Settings>Tools>Actions on Save
  • Option-Option-down/up arrow: Select multiple lines with cursors:
  • Ctrl-G: Select same text multiple cursors
  • CMD-B: Goto definition
  • CMD-[: go back
  • Shift-Shift: command window
  • CMD-:: Opens project settings
  • CMD-,: Open editor settings
  • SHIFT-F6: Rename
  • OPT-CMD-R: Continue running
  • CMD-F9: Build

All things Java

History

  • 1991: work on Java began as James Gosling.

  • 1996: Version 1 released.

  • 2000: I started using Java with version 3.

  • 2006: Sun starts OpenJDK under a GPL license. OpenJDK become the reference implementation.

  • 2010: Oracle acquires Sun and Java

  • 2019 (JDK8) OracleJDK requires license for production deployment. OpenJDK gains steam.

  • 2021 Oracle relents and makes it open again with option for paid support.

  • 2023 Adoptium becomes the primary location to get OpenJDK

History

Java Goals

  1. It must be simple, object-oriented, and familiar.
  2. It must be robust and secure.
  3. It must be architecture-neutral and portable.
  4. It must execute with high performance.
  5. It must be interpreted, threaded, and dynamic.

Installations

Install the zip file and add it to your path. Adoptium is considered the best place to go.

I actually installed by installing IntelliJ and then having it install the JDK for me.

I then added the following to my .zshrc so that I could launch from the console.

alias idea='open -na "IntelliJ IDEA CE.app" --args '

Versions

  • 8:
    • Lambdas
      Runnable runnable = () -> System.out.println("Hello world two!");
    • Function style collections
      List<String> list = Arrays.asList("franz", "ferdinand", "fiel", "vom", "pferd");
    • Stream chaining
      list.stream()
.filter(name -> name.startsWith("f"))
.map(String::toUpperCase)
.sorted()
.forEach(System.out::println);
  • 9: more stream and collection functions. HTTP client
  • 13: Unicode 12.1 support, new switch syntax, multiline string with """ syntax
  • 16: Records
  • 18: UTF-8 is default. jwebserver HTTP server
  • 20: HTTP/3 support

Configure IntelliJ

  • Added Reformat code action on Save in the Tools settings

Building

To run from the console use:

java -classpath out/production/spell spell.Main notsobig.txt cow

To build a jar file from the output use:

java -classpath spell.jar spell.Main notsobig.txt cow

Streams, lambdas, and optionals

Here is an example of using stream, lambda, and optional to get the root cause of an exception. This is really not that much cleaner than more explicit code, but it seems to be where the cool Java kids are going.

It is interesting that you can pass a method to the iterate function and it uses reflection to find that method on the object. This must be most useful the the hasNext/next iteration.

        Optional<Throwable> rootCause = Stream.iterate(e, Throwable::getCause)
                .filter(element -> element.getCause() == null)
                .findFirst();

Method reference

You can use a method reference for any parameter, that is expecting a Functional Interface, as a more concise representation. This is useful in places like lambda functions or in a switch statement.

  Spark.post("/user/register", (r, s) -> service.userRegister(r, s));
  Spark.post("/user/register", service::userRegister);

Implementing SpellChecker

  1. You have four hours to complete the exam. There are three tries with decreasing max value (100, 80, 60). Save 30 minutes to upload your artifacts.
  2. Clone the repository
  3. Create a project named SpellCorrector
  4. Move the source code into src/spell
  5. Move the tests into src/passoff
  6. Move the jar files into jar
  7. Add the jar files to the project structure > project settings > module > dependencies
  8. Create Trie, SpellCorrector, and Node classes and implement the stub of their interfaces.
  9. Implement Node
    1. Add child array and value properties
    2. Implement INode methods
  10. Implement Trie
    1. Add root Node
  11. Add default Trie toString, hashCode, and equals methods.
    1. toString must return a new line separated list of words.
    2. hashCode must not use any of the automatic hashing functions.
    3. equals must not use hashCode or toString
  12. Add creation of SpellCorrector to main class
  13. Run TrieTest and fix until they all pass
    1. Most of the code is in Trie. These are just recursive functions for manipulating INode.
    2. I started with the generated functions for toString, hashCode, and equals and then tweaked them to work.
    3. I did implement equals on Node and then just compared the root nodes of Trie.
  14. Run SpellTest and fix until they all pass
    1. Implement the SpellCorrector.useDictionary method using File and Scanner.
      public void useDictionary(String dictionaryFileName) throws IOException {
    var trie = new Trie();
    try (Scanner scanner = new Scanner(new File(dictionaryFileName))) {
        while (scanner.hasNext()) {
            String n = scanner.next();
            trie.add(n.toLowerCase());
        }
    }
}
  15. Just remember File and Scanner and that it uses hasNext and next to iterate.
  16. Make sure you lowercase the words passed to suggestSimilarWord.
  17. All of the edit functions take a form of two substrings being combined in some way.
      private void calculateAlteration(String inputWord, ArrayList<String> words) {
  for (var i = 0; i < inputWord.length(); i++) {
      for (var c : Trie.alphabet) {
          if (inputWord.charAt(i) != c) {
              var p = inputWord.substring(0, i);
              var s = inputWord.substring(i + 1);
              words.add(String.format("%s%c%s", p, c, s));
          }
      }
  }
}
  18. Collect the matching results and return the one that has the highest value.
  19. If nothing matches then run it again with the list from edit distance 1.

Similarity definition

The following rules define how a word is determined to be most similar:

  1. It has the “closest” edit distance from the input string
  2. If multiple words have the same edit distance, the most similar word is the one with the closest edit distance that is found the most times in the dictionary
  3. If multiple words are the same edit distance and have the same count/frequency, the most similar word is the one that is first alphabetically

Edit distance

  1. Deletion Distance: A string s has a deletion distance 1 from another string t if and only if t is equal to s with one character removed. The only strings that are a deletion distance of 1 from “bird” are “ird”, “brd”, “bid”, and “bir”. Note that if a string s has a deletion distance of 1 from another string t then |s| = |t| -1. Also, there are exactly |t| strings that are a deletion distance of 1 from t. The dictionary may contain 0 to n of the strings one deletion distance from t.
  2. Transposition Distance: A string s has a transposition distance 1 from another string t if and only if t is equal to s with two adjacent characters transposed. The only strings that are a transposition Distance of 1 from “house” are “ohuse”, “huose”, “hosue” and “houes”. Note that if a string s has a transposition distance of 1 from another string t then |s| = |t|. Also, there are exactly |t| - 1 strings that are a transposition distance of 1 from t. The dictionary may contain 0 to n of the strings one transposition distance from t.
  3. Alteration Distance: A string s has an alteration distance 1 from another string t if and only if t is equal to s with exactly one character in s replaced by a lowercase letter that is not equal to the original letter. The only strings that are an alternation distance of 1 from “top” are “aop”, “bop”, …, “zop”, “tap”, “tbp”, …, “tzp”, “toa”, “tob”, …, and “toz”. Note that if a string s has an alteration distance of 1 from another string t then |s| = |t|. Also, there are exactly 25* |t| strings that are an alteration distance of 1 from t. The dictionary may contain 0 to n of the strings one alteration distance from t.
  4. Insertion Distance: A string s has an insertion distance 1 from another string t if and only if t has a deletion distance of 1 from s. The only strings that are an insertion distance of 1 from “ask” are “aask”, “bask”, “cask”, … “zask”, “aask”, “absk”, “acsk”, … “azsk”, “asak”, “asbk”, “asck”, … “aszk”, “aska”, “askb”, “askc”, … “askz”. Note that if a string s has an insertion distance of 1 from another string t then |s| = |t|+1. Also, there are exactly 26* (|t| + 1) strings that are an insertion distance of 1 from t. The dictionary may contain 0 to n of the strings one insertion distance from t.

Results

  1. I implemented this three times. Once to figure it out. A second time to see if I could do it again. This time I took careful notes (above). A third time to time myself. Each time I created a totally different solution.
  2. On the third time, without using my notes, I was able to complete this in 1:45 minutes.
  3. I find this very nerve racking. It forces me to go as fast as possible without thinking if the architecture is good.
  4. The tests are vital. Just let them guide your efforts.
  5. The basic outline is:
    1. Create an empty project and copy in the interfaces, tests, jars, and test files.
    2. Implement main, and the stubbed classes. Set up the project to reference the jars.
    3. Implement reading spell checker file and simply returning the given word.
    4. Run the trie tests
    5. Implement Trie and Node find and add ability.
    6. Implement toString
    7. Implement hashCode and equals
    8. Run Spell tests
    9. Implement a class to track the candidate words, the generated words, the best current match, and to generate candidates using insertion, deletion, alteration, and transposition.
    10. Use the class for edit distance one, with the input word as the candidate.
    11. Use the class for edit distance two, with edit distance one's generated words and the candidates.

Chess

Codebase

git clone https://github.com/BYUCS240TA/Chess.git

Top level

  1. example-chess-projects - Project solutions
  2. specifications - Specifications. This is what is given to the students
  3. Example Chess Projects - Old stuff, maybe we can kill this now?
  4. Specs - Old stuff, maybe we can kill this now?
  5. proguard-7.3.2 - Used to obfuscate the test driver code

Project level (specifications)

The chess project is divided into 6 different projects.

  1. 1-chess-game - Basic board setup and moves. When the tests all pass the student is done.
  2. 2-server-design - Stubbed implementation of service endpoints. Produce the JavaDocs to pass off this deliverable. It isn't clear to me from the documentation what endpoints or code structure is required. There is an API_Calls.txt file in the root that details the endpoints. Are we going to give them that information? The diagram seems to indicate that there is a required structure to the code (Server, Handlers, Services, Data Access, Models), but I'm not sure that is enough to actually produce what you are hoping for. Honestly, I'm not sure what I am supposed to produce for this.
  3. 3-web-api - Actually implement the service. Lots of detail here about what is to be built. When the tests all pass the student is done.
  4. 4-database - Implement the database. When the tests all pass the student is done.
  5. 5-pre-game - Implement the client. When the tests all pass the student is done.
  6. 6-game-play - Implement the game using WebSocket for communication. When the tests all pass the student is done.

Database

It looks like the backend database is expected to be mysql and it is hard coded to look for it on the same server as the code is running on.

localhost:3306/chess

CREATE DATABASE IF NOT EXISTS chess;
SHOW databases;

We need to change the root user and password found in Database.java.

private static final String DB_USERNAME = "chessadmin";
private static final String DB_PASSWORD = "monkeypie";

Users

SELECT user FROM mysql.user;
CREATE USER IF NOT EXISTS chessadmin IDENTIFIED BY 'monkeypie';
GRANT CREATE, SELECT, INSERT ON chess.* TO chessadmin;

Building it for myself

1-chess-game

I followed the instructions GettingStarted-ChessGame.docx in order to get the project set up.

  1. Create project
  2. Create main, starter, and test under src dir. Mark main and stater as "Sources root", mark test as "Test root".
  3. Copy over chess and passoffTeests folders from the specification provided code.
  4. Added org.junit.jupiter:junit-jupiter:5.9.2 as a dependency from Maven.
  5. Reviewed ChessGame.docx. This basically tells the class structure and how to setup the tests. The rules of chess are also covered.

I then created a stub for the required interfaces (board, game, move, piece, and position) in a chess package.

I then starting with BishopMoveTest. After a bunch of boilerplate code and hashCode and equals functionality I finally got the tests to pass. You must make sure you check the color of the pieces.

I continued working through the different pieces. I had to add a history of moves to board in order to get castle and en passant to work. Java is coming back to me. I am not quite sure the interfaces are correct. I have to cast the implementations in several cases (especially with board) in order to provide the operations I need. I could use static methods, but it seems like operations like isSquareEmpty or isOriginalPosition make sense for the board interface. Perhaps this should all be on game. That actually makes more sense, but we only pass around board. I suppose I could add static methods to game that do my helper calculations. Some are very specific though, such as when I calculate en passant I need to access the history of moves.

I got all the tests to pass after about 7 days (~15 hours) with 25 commits.

2-server-design

This module took me about 4 hours to do. The trick is defining what is "good" design. This is a very opinionated subject. It is probably worth some time talking to the class about this. What is "right", "wrong", "fad", and "fantasy".

It seems to me that 2 and 3 modules are backward. At least there has to be a high level design that isn't discussed. It should start from the user's perspective and work its way down to the database. With the user's actions defined, you can talk about objects, with objects you can talk about endpoints, and finally what you are going to store in the database.

I followed the instructions GettingStarted-ServerDesign.docx and copied over the single exception class file. I then reviewed ServerDesign.docx. This basically says make classes for the services, request, response, DOA, and model classes.

Server Design

We use the term service when I think we really mean endpoint. A service usually refers to a collection of endpoints that serve a particular function.

It feels a bit clumsy to have a Game in both the chess and model packages. If the model package represents the persistent data objects then why is there an embedded property that contains the Game. Do those properties get stored in the database? If not then how to you persist the actual moves of a game?

The next step is to diagram out my service. I'm afraid I won't design it the way the example does. However, here are the pieces I will create:

  • Model for user, game, auth.
  • DAO for each of the model objects.
  • Service class
  • Endpoint class for
    • Clear - this is a weird one because it doesn't require auth
    • Register
    • Login
    • Logout
    • List games
    • Create game
    • Join game (as player or observer)
    • (not in spec) Leave game
    • (not in spec) Get board
    • (not in spec) Make move (maybe is this over websocket?)
    • (not in spec) notify of move (maybe is this over websocket?)
  • Request class for each endpoint that converts JSON to parameters.
  • Response class for each endpoint to converts parameters to JSON.

https://mermaid.live/

classDiagram
    class Service {
        databaseClear(req, res)
        userRegister(req, res)
        userLogin(req, res)
        userLogout(req, res)
        gameList(req, res)
        gameCreate(req, res)
        gameJoin(req, res)
    }

    class Database {
        authRegister() Auth
        authLogin() Auth
        authLogout()
        userCreate() User
        userGet() User
        gameCreate() Game
        gameUpdate()
        gameList() Game[]
    }

    Service --> Database
    Service --> Request
    Service --> Response
    Database --> User
    Database --> Game
    Database --> Auth

    class User {
        name : string
        id : id
    }

    class Game {
        name : string
        id : id
        black : id
        while : id
        turn: id
        board: char[][]
        observers : id[]
    }

    class Auth {
        token : string
    }

    class Request {
        body: JSON
    }

    class Response {
        send(status:int, body:JSON)
    }

I created a package for service, dataAccess, and model. I then populated the packages with a single class for Database, a Request and Response class, a single Service class that provides all of the endpoints, and model classes for User, GamePlay (to differentiate it from the chess.Game class), and Auth.

JavaDocs

Trying to get rid of all the warnings that the JavaDoc compiler outputs reminded me of all the reasons I don't write comments. Uncle Bob does a good just specifying why. This article echos his points:

http://asolntsev.blogspot.com/2010/05/why-devil-invented-javadoc.html

I prefer to use:

  • Properly named functions
  • Short functions that do one thing
  • Tests
  • Code navigation that you can step through to really see what it does
  • Comments when the business logic is complex or not clear from the code
  • Comments for public endpoints where the tests can code cannot be referenced

Here are a couple of examples of comments that could be improved (or eliminated):

/**
 * Provides access to the ChessServer
 * Is obfuscated into a Jar to keep hidden from students
 */
public class TestServerFacade {}

The problem with this is Why? Why is it important to keep it hidden from students? Even with obfuscation Intellij we simply decompile it. What is it that we don't want students to have?

    /**
     * Adds a chess piece to the chess board
     * @param position where to add the piece to
     * @param piece the piece to add
     */
    void addPiece(ChessPosition position, ChessPiece piece) {}

In this example the code is better docs than the docs. The variable names speak for themselves, but by adding JavaDocs you have just created maintenance overhead. Plus the docs are just bad. They stutter. addPiece() Adds a piece, Piece the piece to add - Really?

3-web-api

This one looks pretty big. Hook up the server, write the endpoints, store data in memory, and write tests.

I read the WebAPI document and there are some pretty details requirements about how to structure the code. It might be good if some of that was given in the design section. I had to go back and change my model objects based upon the requirements in this module.

There is no description of how the game will actually be played. I think we need a big picture overview in here somewhere.

  • Shouldn't clear be a DELETE instead of a POST.
  • How do you observe?
  • How do you actually play the game?
  • If you can login with a username, then what is the point of the userid or email? Are all three of them unique keys?
  • Trying to register an existing user should return 409 (conflict), not 403 (forbidden).
  • Returning success should instead just use HTTP status codes. Errors can have descriptive messages.
Endpoint Purpose Description
/user/login Log in a user A request body must be supply the username and password. If login succeeds, an authorization authToken is returned. Use the authToken on other API calls that require authorization. The returned JSON object contains "Authorization" (the authorization authToken) and "username" (the username that was just logged in). No authorization authToken is required to call this endpoint.
/user/register Register a user Returns the same JSON object as log in, including an authorization authToken. You may use the authToken with future requests that require authorization. No authorization authToken is required to call this endpoint.
/user/logout Logs out an authenticated user Returns JSON result with success status, or if failed error message describing reason. An authToken is required to call this endpoint.
/games/list Lists all the games in the database This API does not take a request body. The response JSON lists all the games, including the board. An authToken is required to call this endpoint.
/games/create Create a new Chess Game The request body must contain a name for the game. The response JSON contains the ID of created game, a success status and, if failed, an error message describing the reason. An authToken is required to call this endpoint.
/games/join Join a Chess Game The request body must contain the game ID, as well as what color the user wants to claim. The response JSON contains a success status and, if failed, an error message describing the reason. An authToken is required to call this endpoint.
/games/watch Watch a game The request body must contain the game ID. The response JSON contains a success status and, if failed, an error message describing the reason. An authToken is required to call this endpoint.
/clear Clear ALL data from the database This includes users and all game data. No authorization authToken is required.

Web

I rewrote the web interface to be a little more modern, while still being vanilla JavaScript.

Starter Code

Followed the directions for copying over the libs, serverTests, and web. Installed the required libs. Note that gson is included both in the libs and the requested maven dependencies.

Writing the server

Spark docs Spark Tutorial

Here is an example of using different times of Route implementations for a Spark handler.

package server;

import spark.*;

import static spark.Spark.*;

public class Server {
    public static void main(String[] args) {
        port(8080);
        externalStaticFileLocation("web");

        Spark.get("/hello1", (request, response) -> "Hello1");
        get("/hello2", (request, response) -> handle(request, response));
        get("/hello3", new Cow());
    }

    static public Object handle(Request req, Response res) throws Exception {
        return "Hello2";
    }


    private static class Cow implements Route {
        public Object handle(Request req, Response res) throws Exception {
            return "Hello3";
        }
    }
}

Spark supports path parameters.

get("/hello/:name", (request, response) -> "Hello " + request.params(":name"));

I created a single Server, Service and Database class that handles all the endpoints and database operations. I used the model classes for most endpoint request and responses, but had to create a couple specialized classes for response/requests that are non-standard.

I probably spend 6 hours on this. Pretty easy plumbing work. Spark is OK. It would be nice if it supported JSON directly and also had the concept of middleware like Express does.

4-database

Followed GettingStarted-Database and copied over the test file and the dataAccess database file. Changed the password to match my database.

Added com.mysql:mysql-connector-j:8.0.33 to my libraries using Maven. The docs didn't have com. on the front. Mistake?

Manually stopping and restarting the server during the tests is a bit weird. Why doesn't the test just start up and restart the server?

If I don't restart the server everything works fine and so I am ready to actually plug in the database.

There is a nice document that tells you how to install MySQL.

I'm not a huge fan of the unit test requirement for the web-api and database modules. It seems like the higher level HTTP tests do a great job testing the code, and adding more tests just creates maintenance. Of course this is good practice, but wouldn't it be better to just add tests the to the existing suite?

It is interesting that the database.java file was provided to establish the connection. Was that considered too hard for the students to do?

Why doesn't the database.java file use a connection pool?

I like the new automatic resource management functionality that works on anything that implements AutoClosable.

try (var conn = db.getConnection()) {
    try (var preparedStatement = conn.prepareStatement("UPDATE users SET name = ? WHERE id = ?")) {
        preparedStatement.setString(1, "John Doe");
        preparedStatement.setInt(2, 100);
        preparedStatement.executeUpdate();
    }
} catch (SQLException e) {
    throw new DataAccessException("Unable to configure database");
}

Not a huge fan of MySQL in Java. Feels really clunky. There must be some good libraries out there that make it easier.

I need to do Type conversion for all of the piece types so that Gson can properly recreate the objects.

It seems like there is a problem with the starter database code. It isn't multithreaded. It creates a single connection and returns it to everyone who asks. So if two endpoints execute at the same time they are going to have a problem.

I had to write an serialization adaptor to make sure the Piece class was created with proper sub-class.

    private static final TypeAdapter<Piece> chessPieceTypeAdapter = new TypeAdapter<>() {
        @Override
        public void write(JsonWriter w, Piece chessPiece) throws IOException {
            if (chessPiece != null) {
                w.beginObject();
                w.name("pieceColor");
                w.value(chessPiece.pieceColor.toString());
                w.name("type");
                w.value(chessPiece.type.toString());
                w.endObject();
            } else {
                w.nullValue();
            }
        }

        @Override
        public Piece read(JsonReader jsonReader) {
            Piece chessPiece = new Gson().fromJson(jsonReader, Piece.class);
            if (chessPiece != null) {
                chessPiece = Piece.create(chessPiece.pieceColor, chessPiece.type);
            }
            return chessPiece;
        }
    };

    public static TypeAdapter<Piece> getJsonTypeAdapter() {
        return chessPieceTypeAdapter;
    }

This took me about 5 hours. Easy plumbing work.

5-pre-game (Client)

Followed instructions in GettingStarted-Pregame.

  • Created client module
  • Created shared module
  • Setup dependencies on shared module for myChess (server) and client
  • Moved shared files to Shared module
  • Created client JAR. After building the JAR I can run it with: java -jar client.jar

Read Pregame. Not really enough info here to know how to get started building the REPL.

I'm a bit confused on what the instructions for testing are. Am I testing my ServerFacade? Am I supposed to write that now? The instructions seems to indicate that I wasn't suppose to implement game play yet.

I spent a lot of time remembering how reflection works in Java. Also relearned how to build an HTTP client (painful in Java). Playing around with console output to move things around. Surprised that they don't backspace the board for display in the example. Implementing tests for my eval function since there are no provided tests for this module. Painting the board is painful because the colors display differently on different terminals. After about 16 hours of work I got everything working.

I had to type cast board so that I could tell it how I wanted toString to paint the board. The other possibilities is to expose the ability to access the board array.

6-game-play (WebSocket)

Jul 18 1:00

The protocol is named WebSocket, not Web Socket or WebSockets.

Copied over the test and WebSocket files from StarterCode-Gameplay as specified in the getting started instruction.

I don't understand why the leave command is available for players? Don't they have to resign? Is that an automatic resign? Also what is the point of not leaving the game on resign?

I don't understand why there is a join HTTP and JOIN_PLAYER WebSocket message.

How do you enable the ability to redraw the board without an endpoint to get the board from the server? I guess you just redraw what the client has cached?

Why have each client keep their own copy of the board. Why not just have the server send out the board after every change?

Does a player have to resign if they are checkmated?

You have to name your ws endpoint connect in order for the tests to work.

https://sequencediagram.org/index.html#initialData=C4S2BsFMAIHEEMC2MAK54E8BQWAO8AnUAYxHwDthoBlSAgNzq3mOAHsDo1M6BGZ1hy7oMdAEwD2nAPIAjAM51GBflgC8agDJsA5iHIascxQz4BaAHy1TBAFza95aMaV9o+efIDuHACZZuUQIxS2tle119YR5g93hPHwJ-QPMrVzsHKJSVOIS-HA0EZGhiAkh4UDYDNQCRVLC6WwBhMoqYIsh+bN5Q9NsAKTYojt5oACFNAEEmgGlamJ7emwHpAEkAOQB9FCmATQBRACUsBoIzS277aUmAEU3YSYBZffmgkLTlzRB5YFfxJfCg2GSE60AA6gAJVYAFRe2RCAMa-TWWx2kwOx1O5ws8Kut3uTxeWIudRUtnW0mhqwAYqsmpMqdJ1tAABQAKyGTnh0Fk6GIAGsAJRGBTpHofcJfH4ikzKcWnAacuAg-guGyLCVIlGbaRjahHABqRxO6WxarleLuD2eJps2MuFKptPpjOZ7KV5rcbFFNmFxJxpLE5MpNLpDNWTNZHKinpy3tldGF6jUHXcIkM3WxCsekxm+02j2kRugkDEkAALLblPbSbxLQSbf7cZprlbCVW6GafRaW-jrUTTSSFsGnWHXazEGxGCWy+W-YOAzEg47Qy6I27J9PSxX53bLLG6yvneHIyzNzBt3OCimQSUqsRwABXeQgKoZ2tZvqHfbUVawdYdmcQ5BIeIbHuOLJlC+OhcrWu7VsB4gjquJ5ulBIAwdEIHwZ2+7dnwyHgeurLoZh3RJvCn6fPskxGoBNbDkeY7ESyUDwNO8I4UBFgHoRzGnmxHGBkmMpilRko0XROA4EAA

Server

Setting up the websocket on the server is pretty trivial.

import com.google.gson.Gson;
import org.eclipse.jetty.websocket.api.*;
import org.eclipse.jetty.websocket.api.annotations.*;
import webSocketMessages.userCommands.UserGameCommand;
import static spark.Spark.*;

@WebSocket
public class WebSocketHandler {
    public static void main(String[] args) {
        webSocket("/connect", WebSocketHandler.class);
        init();
    }


    @OnWebSocketConnect
    public void onConnect(Session user) throws Exception {
        System.out.println("connection opened");
    }


    @OnWebSocketClose
    public void onClose(Session user, int statusCode, String reason) {
        System.out.println("connection closed");
    }


    @OnWebSocketMessage
    public void onMessage(Session user, String message) throws java.io.IOException {
        System.out.println("message received: " + message);

        UserGameCommand command = new Gson().fromJson(message, UserGameCommand.class);
        System.out.println("JSON received: " + new Gson().toJson(command));
        user.getRemote().sendString("hello");
    }
}

Why is GameDataCache a global singleton? Why not just make it a member of the GameConnectionHandler?

Need test for making multiple moves.

I needed to add the database serialization adapters since Piece has subclasses. It is a bit strange because each piece only differs by methods, not that actually data of the piece. Perhaps it would be better if it was just methods for the pieces rather than classes.

If you want to run the game from the console you can use:

java -cp out/production/client:out/production/shared:libs/gson-2.10.1.jar:libs/tyrus-standalone-client-1.15.jar ui.Repl

Client

To set up the client WebSocket communication we use the JDK javax.websocket.endpoint interface with the glassfish.tyrus.bundles.standalone.client.jdk implementation. I don't know where I first installed that, but it is there in my libs.

{
  "board": {
    "squares": [
      [
        { "pieceColor": "WHITE", "type": "ROOK" },
        { "pieceColor": "WHITE", "type": "KNIGHT" },
        { "pieceColor": "WHITE", "type": "BISHOP" },
        { "pieceColor": "WHITE", "type": "QUEEN" },
        { "pieceColor": "WHITE", "type": "KING" },
        { "pieceColor": "WHITE", "type": "BISHOP" },
        { "pieceColor": "WHITE", "type": "KNIGHT" },
        { "pieceColor": "WHITE", "type": "ROOK" }
      ],
      [
        { "pieceColor": "WHITE", "type": "PAWN" },
        { "pieceColor": "WHITE", "type": "PAWN" },
        { "pieceColor": "WHITE", "type": "PAWN" },
        { "pieceColor": "WHITE", "type": "PAWN" },
        { "pieceColor": "WHITE", "type": "PAWN" },
        { "pieceColor": "WHITE", "type": "PAWN" },
        { "pieceColor": "WHITE", "type": "PAWN" },
        { "pieceColor": "WHITE", "type": "PAWN" }
      ],
      [null, null, null, null, null, null, null, null],
      [null, null, null, null, null, null, null, null],
      [null, null, null, null, null, null, null, null],
      [null, null, null, null, null, null, null, null],
      [
        { "pieceColor": "BLACK", "type": "PAWN" },
        { "pieceColor": "BLACK", "type": "PAWN" },
        { "pieceColor": "BLACK", "type": "PAWN" },
        { "pieceColor": "BLACK", "type": "PAWN" },
        { "pieceColor": "BLACK", "type": "PAWN" },
        { "pieceColor": "BLACK", "type": "PAWN" },
        { "pieceColor": "BLACK", "type": "PAWN" },
        { "pieceColor": "BLACK", "type": "PAWN" }
      ],
      [
        { "pieceColor": "BLACK", "type": "ROOK" },
        { "pieceColor": "BLACK", "type": "KNIGHT" },
        { "pieceColor": "BLACK", "type": "BISHOP" },
        { "pieceColor": "BLACK", "type": "QUEEN" },
        { "pieceColor": "BLACK", "type": "KING" },
        { "pieceColor": "BLACK", "type": "BISHOP" },
        { "pieceColor": "BLACK", "type": "KNIGHT" },
        { "pieceColor": "BLACK", "type": "ROOK" }
      ]
    ],
    "history": []
  },
  "turn": "WHITE"
}

About

No description, website, or topics provided.

Resources

Readme
Activity

Stars

0 stars

Watchers

1 watching

Forks

0 forks
Report repository

Languages
